HID range of door controllers includes advanced, scalable, and secure solutions designed to meet small to large access control requirements with support for Wiegand and OSDP communication. The HID Aero X1100 (X1100A) is a 2-door, 2-reader intelligent controller expandable up to 64 doors and 64 readers through interface modules such as X100A Door/Reader Interface, X200A Input Monitor Module, and X300AP Output Control Module. It supports up to 250, 000 credentials, secure TLS 1.2 communication, AES-256 encryption, and has 7 supervised inputs, 4 relays, and Ethernet connectivity. The VertX EVO series offers the V1000 Master Controller (71000) and V2000 2-Door Controller (72000), expandable with interface modules including V100 Reader Interface (70100), V200 Input Monitor (70200), and V300 Output Control (70300), supporting up to 250, 000 cardholders. The EDGE EVO series provides IP-based single-door solutions such as EH400-K, EHR40-K, and EHR40-L, featuring integrated iCLASS readers, Wiegand/Clock-and-Data support, 4 inputs, 2 outputs, and secure door modules for localized intelligence. For standalone or smaller setups, options include the Advantage DG Master Controller (23-206) with keypad and HID reader supporting 2, 000 cards, 2 relays, transaction logging, anti-passback, and temperature range from -15 to 175 °F, as well as the DAC-KP002 Standalone Controller, a waterproof IP-68 rated unit supporting 1–2 doors with 2, 000 users, PIN and proximity card modes, dual relays, tamper alarm, and operating temperature from -45 °C to 55 °C. This complete range covers intelligent networked controllers, modular expansion devices, IP-based single-door solutions, and rugged standalone units, making HID controllers versatile and reliable for enterprise, commercial, and industrial access control environments.
